STM-Q100
SMART
| Availability: | |
|---|---|
| Quantity: | |
Worktable | Workbench Size | mm | 1000*1000 |
Maximun Load of Workbench | kg | 2000 | |
Number of Workbenches | pcs | 1/2 | |
| Workbench Indexing | deg | 1° | |
| Exchange Structure Type | APC | Gyrotype | |
| Workbench Exchange Time | sec | 24 | |
| Form of Worktable | T | 5*22*200 | |
| Maximum Workpiece Rotation Diameter | mm | Φ1280 | |
Trip | Workbench Moves Left and Right(X-axis) | mm | 1300/1600 |
Spindle Box Up and Down Movement(Y-axis) | mm | 1000 | |
Column Moving Forward and Backward(Z-axis) | mm | 1000 | |
Main Shaft | Spindle Taper | - | BT50 |
Spindle Speed(Standard) | rpm | 6000 | |
Main Shaft Transmission Form | - | Belt /ZF Gearbox (optional) | |
Spindle Additional Functions | - | Ring Spray/Center Water (optional) | |
Spindle Motor Power | - | 22/26 | |
| Maximum Output Torque of Spindle | N·mm | 160/640 | |
| Distance From Centerline of Spindle to Workbench | mm | 0-1000 | |
| Distance From Spindle end face to Workbench Center | m | 200-1200 | |
Feed System | Repeatability X/Y/Z axis | m/min | 24/24/24 |
Repeatability B-axis | r/min | 10 | |
| Feed Rate X/Y/Z axis | mm/min | 0-10000 | |
Accuracy (Optional Optical Ruler) | Positioning Accuracy | mm | 0.012 |
| arc-sec | 12 | ||
| Move in Quickly to give speed | mm | 0.006 | |
| acr-sec | 6 | ||
| Tool Magazine System | ATC Tool Maximum Diameter (Adjacent/Non Adjacent) | mm | Φ125/250 |
| Maximum Weight of ATC Tool | kg | 18/25(Optional) | |
| Magezine Capacity | T | 40(60) | |
| Maximum Tool Length | mm | 450 | |
Installtion Requirements | Guide Rail Specifications | mm | Heavy Duty 55 Linear Guide |
| Machine Weight | kg | 22000 |
